Carbon Fiber/Resin Composite
This is a polished cross-section of a carbon fiber/resin composite layup showing the boundary between two plies.
Reflected Brightfield Illumination
Definition/Function:
Resin reimpregnated carbon fiber plies are oriented in different directions when making a large layup to optimize the physical properties of the final cured part.
