Cotton Fibers Through the Microscope

Cotton Fiber

The apparent twist in these fibers is typical of cotton. A unique optical property of cotton is its lack of an extinction position. As the stage is rotated between crossed linear polarizing filters the fiber's brightness doesn't significantly change.

Transmitted Cross Polarized Light Illumination

Definition/Function:

Cotton is a very common clothing and bedding fiber. Hospital gowns, lab coats, and other company or facility provided outer garments are offen made of cotton. Free cotton fibers are very common in bedroom samples and in hospital and laboratory environments. It is also the main fiber in common shop rags. When cotton is mercerized the twist is greatly reduced and the fiber tends to darken significantly on rotation between crossed linear polarizers.

Cotton comes from the fiber on the outside of the seeds of a number of species of the genus Gossypium. Gossypium hirsutum is the most common commercial type of cotton. Other common commercial cotton species include arboreum, barbadense, and herbaceum. There are also a number of hybrids used commercially.

Significance in the Environment:

This is a common clothing fiber.

Characteristic Features:

Cotton has a refractive index along its length of about 1.56 to 1.59 and perpendicular to its length of about 1.52 to 1.54. It has a birefringence of up to 0.05 and a positive sign of elongation. Cotton is typically a twisted ribbon in appearance under the microscope but the frequency of the twists varies with maturity of the fibers, they species of fiber, and chemical processing of the fiber (Mercerization). Mature cotton fiber of the species hirsutum has no extinction position. This property varies in other species.

Associated Particles:

References:

DuPont Company Techinical Bulletin X-156: IDENTIFICATION OF FIBERS IN TEXTILE MATERIALS, December 1961.
