Interference Colors, Tape Wedge

Interference Colors, Tape Wedge

These are the interference colors shown by successive layers of a plastic tape with a retardation of approximately 24.5 nanometers per layer when viewed between crossed polarizing filters. The successive layers of tape can be counted by the successive serrations at the end of each layer. There are approximately 44 layers of tape at the extreme left side of the image and the color seen there corresponds to a retardation of approximately 1078 nanometers (44X24.5). The first layer is just barely visible at the extreme right of the image, the color that corresponds to a retardation of 24.5 nanometers.

Transmited Crossed Polarized Light Macrophotograph

Definition/Function:

Interference colors can be created by viewing a material that has a regular asymmetry in its molecular structure between polarizing filters. "Crossed Polars" means that the two polarizing filters are in an orientation that prevents any direct light from passing through the two filters. If a material with aligned molecules or with a crystal structure other than cubic is placed between the two filters in this orientation then interference colors become visible. The color depends on the structure in the material and the thickness of the material. The structure of the material can be characterized by the maximum and minimum refractive index of the material. These two refractive indices are always at 90 degrees to one another. The difference between these two, maximum minus minimum, is the "birefringence" of the material. The birefringence times the thickness is the "retardation".

Significance in the Environment:

Characteristic Features:

Associated Particles:

References:
