Copper "Trees" on Aluminum
This is an example of copper trees growing on a small
particle of aluminum foil in a large transformer bushing.
Darkfield Reflected Light Illumination
Definition/Function:
Copper trees will grow on a small fragment of aluminum in bushing oil when copper is
taken into solution in the oil.
Copper will plate the aluminum if only very low levels of copper are present.
Significance in the Environment:
This indicates that the oil is corrosive to copper and that some of the copper compounds
formed are soluble in the oil.
Characteristic Features:
The reddish color of the copper stands out in sharp contrast to the white of the
aluminum. Even in low concentrations the copper plating out
on the aluminum will be easily visible.
Associated Particles:
References:
